Place of Origin: | China |
Brand Name: | JOYBAT |
Certification: | CE,Rohs |
Model Number: | JOY402535 |
Minimum Order Quantity: | 200 pcs |
---|---|
Packaging Details: | Carton |
Delivery Time: | 7 days |
Payment Terms: | T/T,Western Union |
Supply Ability: | 3000 Pieces per Day |
Application:
Widely used in mobile phones, notebook computers, consumer electronics, military, aviation products and so on.
Feature:
1. No memory effect.
2. High energy density.
3. High operating voltage.
4. Safety characteristics are excellent.
5. Discharge temperature range of-20°C+60°C.
6. Charge/discharge cycle characteristics are excellent.
Model: 402535
No. | Item | Characteristics | Remarks |
1 | Nominal Capacity |
Minimum: 300mAh Typical: 310mAh |
Fully charged @1C to 4.2V for 2.5 hrs, then discharge to 3.0V @ 0.2C. |
2 | Nominal Voltage | 3.7V | |
3 | Charging Cut-off Voltage | 4.2V | |
4 | Discharge Cut-off Voltage | 3.0V | |
5 | Max. Charging Current | 300mAh(1C) | |
6 | Max. Discharging Current | 600mAh(2C) | |
7 | Operating Temperature |
Charge 0-45°C Discharge -20-60°C |
|
8 | Storage Temperature |
-20-45°C for 1Month -20-35°C for 6Months |
|
9 | Dimension | 4.0*25*35mm | Maximum dimension |
10 | Weight | 18g | Approximate value |
