503759 3.7v 1200mah with PCM and wire,Rechargeable lithium polymer battery 503759 3.7v 1200mah

503759 3.7v 1200mah with PCM and wire,Rechargeable lithium polymer battery 503759 3.7v 1200mah

    • 503759 3.7v 1200mah with PCM and wire,Rechargeable lithium polymer battery 503759 3.7v 1200mah
    • 503759 3.7v 1200mah with PCM and wire,Rechargeable lithium polymer battery 503759 3.7v 1200mah
    • 503759 3.7v 1200mah with PCM and wire,Rechargeable lithium polymer battery 503759 3.7v 1200mah
  • 503759 3.7v 1200mah with PCM and wire,Rechargeable lithium polymer battery 503759 3.7v 1200mah

    Product Details:

    Place of Origin: China
    Brand Name: JOYBAT
    Certification: CE,Rohs
    Model Number: JOY503759

    Payment & Shipping Terms:

    Minimum Order Quantity: 300 pcs
    Packaging Details: Carton
    Delivery Time: 7 days
    Payment Terms: T/T, Western Union
    Supply Ability: In stock
    Contact Now
    Detailed Product Description

    Application:
    Widely used in mobile phones, notebook computers, consumer electronics, military, aviation products and so on.

    Feature:
    1. No memory effect
    2. High energy density
    3. High operating voltage
    4. Safety characteristics are excellent
    5. Discharge temperature range of-20°C+60°C
    6. Charge/discharge cycle characteristics are excellent

    Model: 503759

    No. Item Characteristics Remarks
    1 Nominal Capacity 1200mAh Fully charged @1C to 4.2V for 2.5 hrs, then discharge to 3.0V @ 0.2C.
    2 Nominal Voltage 3.7V
    3 Charging Cut-off Voltage 4.2V
    4 Discharge Cut-off Voltage 3.0V
    5 Max. Charging Current 1200mA(1C)
    6 Max. Discharging Current 2400mA(2C)
    7 Operating Temperature Charge 0-45°C
    Discharge -20-60°C

    8 Storage Temperature -20-45°C for 1Month
    -20-35°C for 6Months

    9 Dimension 5.0*37*59mm Maximum dimension
    10 Weight 22g Approximate value



    Caution:
    1. Do not burn the battery.
    2. Do not disassemble the battery.
    3. Do not make the battery short-circuit.
    4. Do not exceed the specified range of temperature.

    503759 3.7v 1200mah with PCM and wire,Rechargeable lithium polymer battery 503759 3.7v 1200mah503759 3.7v 1200mah with PCM and wire,Rechargeable lithium polymer battery 503759 3.7v 1200mah503759 3.7v 1200mah with PCM and wire,Rechargeable lithium polymer battery 503759 3.7v 1200mah
